ERIN IP54 SENSOR BK
AZ6081
3D Models:
Architect’s Zone
Don’t have an account yet? Register now and gain access to the architect’s zone.
You will be able to browse and download product files.
Product Information
Description
Informacje podstawowe
Type: DOWNLIGHT
Type of light source: LED INTEGRATED
Maximum power: 3W
Energy class: G
Protection class: IP54
Dominant color: BLACK
Main finish: MATTE
Dominant material: ALUMINIUM
Product height [cm]: 18,5
Installation depth [cm]: 16,3
Installation width [cm]: 3,2
Installation length [cm]: 4,2
Light source: 1
Lumens [lm]: 10,5
Color temperature [K]: 3100
Dimmable: NO
CCT: NO
RGB: NO
CRI [Ra]: ≥ 80
Azzardo Smart app: NO
Remote control: NO
Bluetooth control panel: NO
Bluetooth gateway: NO
Motion sensor: YES
Sensor range: DISTANCE: < 4 m. | TIME: < 30 s.
Control options: • MOTION SENSOR
Control type > For all: MOTION SENSOR
Voltage: ~ 230V
Protection class (against electric shock): 2
Net weight [kg]: 0,34
Gross weight [kg]: 0,37
Box 1 depth [cm]: 4,3
