DURANTE IP54 SENSOR CCT BK
AZ6536
3D Models:
Architect’s Zone
Don’t have an account yet? Register now and gain access to the architect’s zone.
You will be able to browse and download product files.
Product Information
Description
Dimensions
Product length [cm]: 21
Wall base height [cm]: 10
Product height [cm]: min. 10 max. 14,5
Wall base length [cm]: 21
Wall base width [cm]:
Lampshade height [cm]: 12,5
Lampshade width [cm]: 3
Lampshade length [cm]: 17,8
Product width [cm]: min. 12 max. 16,5
Materials and colors
Dominant color: BLACK
Accent material: PVC
Dominant material: ALUMINIUM
Main finish: MATTE
Wall base color: BLACK
Shade color: Black
Basic information
Type: WALL
Energy class: G
Protection class: IP54
Maximum power: 21W
Type of light source: LED INTEGRATED
Specifications
Azzardo Smart app: NO
Bluetooth gateway: NO
CCT: YES
Motion sensor: YES
Protection class (against electric shock): 1
Light source: 1
Voltage: ~ 230V
Tilt: 350°
Control options: • CCT SWITCH• TRIAC DIMMER
• MOTION SENSOR
RGB: NO
Dimmable: NO
Remote control: NO
Color temperature [K]: 3000 / 4000 / 6000
Control type > For all: CCT SWITCH
Sensor range: DISTANCE: 0,5 ~ 10 m. | HEIGHT: 2 ~ 2,5 m. | ANGLES: 150° + 90° | TIME: 30 s. ~ 3 min. | DUSK SENSITIVITY
Adjustment: Yes
Packaging details
Gross weight [kg]: 1,5
Net weight [kg]: 1,3
Box 1 depth [cm]: 19
